This image represents the series, but may not be the exact part.

47890/47820 Taper Roller Bearing Premium Brand Koyo 92.075x146.050x33.338mm

Quick Order Code: 218672

Taper Roller Bearing

Availability: Once you have placed your order, we will confirm the factory delivery. If you require this first please use quote icon below.
Want more than we show, or require a bulk item price? - please use Quote button
£54.84 £45.70

Tapered roller bearings comprise solid inner and outer rings with tapered raceways and tapered rollers. Taper roller bearings can support axial forces in one direction and high radial forces.

Example applications

  • Automotive
  • Trailers and caravans
  • Agricultural
  • Gearboxes/differentials
  • Motorcycles
  • Plant machinery

More Information
Brand = KOYO
Manufacturer Part Number = 47890R/20
Inside Diameter = 92.075mm = 3-5/8"
Outside Diameter = 146.05mm = 5-3/4"
Width = 33.337mm = 1-5/16"
Cone Width = 34.925mm
Cup Width = 26.195mm
Dynamic Load = Cr 223 KN
Static Load = Cor 296 KN
Limiting Speed r/min = Grease Lubricant 2500 r/min, Oil Lubricant 3300 r/min
Image = Image represents the series, but may not be the exact part
Alternative Brand = In the very unlikely event that we should not have available free stock in the listed brand, then a quality brand will be supplied.
